Two Component Glue Potting Machine Three-Axis Adhesive Glue
Dispenser Machine for Industrial Production
Features and Benefits:
1. The glue potting system are for AB component materials for
metering, mixing and potting .
2. Accurated metering and evenly mixing helps to avoid possible
waste of glue.
3. Dispensing size and positioning keep consistently and fastly.
4. Good universality makes our machine suitable for applications of
LED, electric and others glue potting and dispensing needed.
5. Easy to program and operate.
6.Fast metering & mixing and running speed keep potting with high
efficiency.
7. Tally function, non-standard mode, tank level alert, filter
mode, liquid display device, preventing backflow device and other
functional device.
Applications:
Reverse Sensor, Electronic Circuit Board, Electronic Ballast ,air
Filters, LED products ,Electronic components,Crafts,Ads modules,
Capacitors, Power supply, Transformer, end cap for filter, solar
junction box ,Power module, Ignition coil, Sensor, Photovoltaic
module, Photovoltaic inverter. Etc
Suitable Material: AB part adhesive , 2K potting compound materials , 2-part materials
, two component potting compound, silicone , epoxy resin,
polyurethane ...
Item
| Parameter |
Mixing Ratio
| 1:1 to 10:1 ajustable |
| Working area |
700*700*100mm
|
Displacement speed
| 200mm/s (speed) Out-glue speed 1-12g/s |
Accuracy
| ±2%(output volume)±2%(mixing) |
Tolerance
| ≤0.2mm |
Flow control
| Digital input |
Program memory
| Digital input |
Motion trail
| Dot, line, curve, circle |
| Automatic controlling system | Touch screen (to achieve program programming, modification, storage
and so on |
Out-glue control system
| AB glue back suction valve, achieve AB glue independent operation |
Programmatically
| Tech programming
With computer systems (Micro software Windows 7,Windows10 optional) |
Mix method
| Static mix or Danamic mix |
Power supply
| 220V/50Hz/1500W |
Air source
| 0.5-0.8Mpa |
Viscosity range
| 50-35000cps |
Outer dimension
| 1500L*1200W*1600H mm |
AB tank size
| 10L,25L,40L optional |
Others
| AB tank ,A pump,AB pipeline heating function |
Features
1,Glue controlling system of metering, mixing and potting.
2,Accurate metering and even mixing helps to avoid the waste of
glue.
3,Dispensing size and positioning keep machine work consistent and
fast.
4,Good universality
5,Easy to program and operate.
6,Tally function, non-standard mode, primer mode, level alert,
filter mode, liquid display device, preventing back-flow device and
other functional device.
Machine description and working principle
Automatic glue mixing machine is mainly used for a two-component
glue( Epoxy/ Silicone/PU,etc adhesive), automatic metering and
mixing the ratio of glue.
The glue are stored in two barrels separately, according the glue
weight ratio and volume demand automatic metering by two sets of
precision pumps, supply to a mixing device fully mixing, and then
potting/dispensing the desired products.
Liquid A & B are kept in two tanks separately. There are two sets
of metering pumps inside the machine, draining out liquids
individually from tank A & B. Liquid A & B mix with each other in
the mixer pipe and dispensed out according to the programmable
data.
Machine description and working principle
Automatic glue mixing machine is mainly used for a two-component
glue( Epoxy/ Silicone/PU,etc adhesive), automatic metering and
mixing the ratio of glue.
The glue are stored in two barrels separately, according the glue
weight ratio and volume demand automatic metering by two sets of
precision pumps, supply to a mixing device fully mixing, and then
potting/dispensing the desired products.
